SICK FLOWSIC600-XT User Manual

Commissioning and Operation
FLOWSIC600-XT · Operating Instructions · 8018846/1BHP/V2-1/2021-05 · © SICK Engineering GmbH 83
Subject to change without notice
4.2.4 Configurable standard display
The standard display comprises 2 display pages that can be toggled by pressing a button.
Each of the three available lines (meter level display + 2x dot matrix) can be configured
individually for each display page.
Meter level display
The following values are available for the meter level display:
Table 10 Meter level display
Line No. Value
Display example
0 No display
1 Volume at flowing conditions, forward, uninter-
rupted
+V 000012345 m³
2 Volume at flowing conditions, reverse, uninter-
rupted
-V 000012345 m³
3 Volume at flowing conditions, forward, interrupted
+
err
V 000000123 m³
4 Volume at flowing conditions, reverse, interrupted
-
err
V 000000123 m³
5 Volume at flowing conditions, forward, total
+
tot
V 000012468 m³
6 Volume at flowing conditions, reverse, total
-
tot
V 000012468 m³
7
[1]
[1] Only visible when volume conversion is active
Volume at base conditions, forward, uninter-
rupted
+ V
b
000012345 m³
8
[1]
Volume at base conditions, reverse, uninter-
rupted
- V
b
000012345 m³
9
[1]
Volume at base conditions, forward, interrupted
+
err
V
b
000000123 m³
10
[1]
Volume at base conditions, reverse, interrupted
-
err
V
b
000000123 m³
11
[1]
Volume at base conditions, forward, total
+
tot
V
b
000012468 m³
12
[1]
Volume at base conditions, reverse, total
-
tot
V
b
000012468 m³
