Commissioning and Operation
Subject to change without notice
Dot matrix display
The following values are available for the dot matrix display:
Table 11 Dot matrix display
Line No. Value
Display example
0 No display
1 Date/time
18.08.2015 13:25:21
2 Gas velocity
VOG 12.34 m/s
3 Sound velocity
SOS 430.34 m/s
4 Operational flow rate
Q 1324.12 m³/h
5
[1]
[1] Only visible when volume conversion is active
Base flow rate
Qb 1324.12 m³/h
6
[1]
Mass flow rate
mf 17.61 kg/h
7 Pressure
P 51.23 bar
8 Temperature
T 18.31 °C
9
[1]
Conversion factor
C 52.123
10
[1]
Compressibility
K 0.96321
11 Volume at flowing conditions, forward, uninter-
rupted
+V 000012345 m³
12 Volume at flowing conditions, reverse, uninter-
rupted
-V 000012345 m³
13 Volume at flowing conditions, forward, interrupted
+Ve 000000123 m³
14 Volume at flowing conditions, reverse, interrupted
-Ve 000000123 m³
15 Volume at flowing conditions, forward, total
+Vt 000012468 m³
16 Volume at flowing conditions, reverse, total
-Vt 000012468 m³
17
[1]
Volume at base conditions, forward, uninter-
rupted
+Vb 000012345 m³
18
[1]
Volume at base conditions, reverse, uninterrupted
-Vb 000012345 m³
19
[1]
Volume at base conditions, forward, interrupted
+Vbe 000000123 m³
20
[1]
Volume at base conditions, reverse, interrupted
-Vbe 000000123 m³
21
[1]
Volume at base conditions, forward, total
+Vbt 000012468 m³
22
[1]
Volume at base conditions, reverse, total
-Vbt 000012468 m³
23
[1]
Mass, forward, uninterrupted
+M 000012345 tn
24
[1]
Mass, reverse, uninterrupted
-M 000012345 tn
25
[1]
Mass, forward, interrupted
+Me 000000123 tn
26
[1]
Mass, reverse, interrupted
-Me 000000123 tn
27
[1]
Mass, forward, total
+Mt 000012468 tn
28
[1]
Mass, reverse, total
-Mt 000012468 tn
