Terminal assignment Ex-e terminal compartment
Fig. 34 Terminal assignment Ex-e terminal compartment
▸ Connection parameters, see → p. 71, §3.4.8.2.
Table 7 Ex-e: Alternative terminal assignments and configurations
13
OC.0 NAM.0
14
GND.0
15
OC.1 NAM.1
16
GND.1
17
OC.2 NAM.2
18
GND.2
19
OC.3 NAM.3
20
GND.3
21
1A TX
22
1B RX
23
COMM
24
n.c.
Vdc +
1
Vdc -
2
pT + 2A
3
pT - 2B
4
aux +
5
+
6
-
7
aux -
8
3A Enc +
9
3B Enc -
10
CTS
11
RTS
12
With Ethernet
13
OC.0 NAM.0
14
GND.0
15
OC.1 NAM.1
16
GND.1
17
OC.2 NAM.2
18
GND.2
19
OC.3 NAM.3
20
GND.3
21
1A TX
22
1B RX
23
COMM
24
n.c.
Vdc +
1
Vdc -
2
pT + 2A
3
pT - 2B
4
aux +
5
+
6
-
7
aux -
8
TX +
Ethernet
9
TX -
10
RX +
11
RX -
12
Without Ethernet
Assignment Alternative Alternative
[1]
[1] If configured
1 Power supply
2
3 HART p & T RS485.2 (MOD),
Modbus RTU
-
4
5 AO, alternative external
auxiliary voltage
-
6
7
8
9 RS485.3 (MOD),
Modbus RTU
Encoder Ethernet
10
11 - -
12
13 DO.0/FO.0
Open Collector
DO.0/FO.0
NAMUR
-
14
15 DO.1/FO.1
Open Collector
DO.1/FO.1
NAMUR
16
17 DO.2
Open Collector
DO.2
NAMUR
18
19 DO.3
Open Collector
DO.3
NAMUR
20
21 RS485.1 (MOD),
Modbus RTU
-
22
23 Not used -
24 Not used
