Batch Reading (IDM2xx series)
IDM corded
© SICK AG · Germany · All rights reserved · Subject to change without notice
45464748 Start character match for Code 93, 45h = “E”, 46h = “F”, 47h = “G”, 48h = “H”
FF End of third code
To program the previous example using specific lengths, you would have to count the programmed Preamble,
Postamble, Scanned Data Length, Prefix/Suffix Symbol ID or AIM ID if you had defined as part of the length. If
you enable the Suffix Symbol ID of symbology, you would add one character to the previous example’s length.
You would set up the Batch Reading rule with the following command line:
[PROGRAM] [Batch Reading] [0301001141FF070011FF09001345464748FF] [FIN] [END]
The breakdown of the command line is shown below:
03 The number of elements in the overall rule
01 Code identifier of Code 128
0011 Code length that must match for Code 128
A-Code 128 sample length (10) plus Suffix Symbol ID (1) = 11
41 Start character match for Code 128, 41h = “A”
FF End of first code
07 Code identifier of Code 39
0011 Code length that must match for Code 39
BC-CODE 39 sample length (10) plus Suffix Symbol ID (1) = 11
FF Universal matched character indicating all characters. Also indicates end of second
code.
09 Code identifier of Code 93
0013 Code length that must match for Code 93
EFGH-CODE 93 sample length (12) plus Suffix Symbol ID (1) = 13
45464748 Start character match for Code 93, 45h = “E”, 46h = “F”, 47h = “G”, 48h = “H”
FF End of third code
If the [Character match(es)] is set to “FF”, the following “FF” which indicates the end of the code does
not have to be set.
STX (RS-232/
USB Com
interface)
Preamble
Scanned
Data
Length
ID or Prefix
AIM Symbol
Scanned Data
modified by
DataWizard
ID or Suffix
AIM Symbol
Postamble
ETX (RS-232/
USB Com
interface)
1 character 1-15
characters
2-4
digits
1 or 3
characters
Variable length 1 or 3
characters
1-15
characters
1 character
