Chapter 12 Operating instructions
S100
56 © SICK AG • Subject to change without notice 8012238/YY30/2015-02-20
Technical specifications
Minimum Typical Maximum
Power-up delay
Of a configured device 15 s
If the configuration is read from the system
plug
25 s
Restart after (configurable) 0 s 60 s
Electrical data
Supply voltage (SELV)
6)
16.8 V 24 V 30 V
Permissible residual ripple
7)
±5%
Switch on current
8)
2 A
Operating current at 24 V without output load 0.25 A 0.33 A
Operating current with maximum output load 1.65 A
Power consumption without output load 6 W 8 W
Power consumption with maximum output
load
40 W
Electrical connection System plug with screw terminal
connections
Technical specifications, screw type
terminal FE
Cross-section of rigid cores 0.3 mm² 1.6 mm²
Cross-section of flexible cores
9)
0.3 mm² 1.6 mm²
American Wire Gauge (AWG) 22 14
Insulation stripping length for the cores 5 mm
Screw tightening torque 0.5 Nm
Technical specifications, screw terminals
Cross-section of rigid cores 0.14 mm² 1.5 mm²
Cross-section of flexible cores
10)
0.14 mm² 1.0 mm²
American Wire Gauge (AWG) 26 16
Insulation stripping length for the cores 5 mm
Screw tightening torque 0.22 Nm 0.3 Nm
Cable length for power supply tolerance ±10%
For wire cross-section 1 mm² 50 m
For wire cross-section 0.5 mm² 25 m
For wire cross-section 0.25 mm² 12 m
6)
The voltage supply must be capable of buffering brief mains voltage failures of 20 ms as specified in
EN 60204. Suitable power supplies are available as accessories from SICK (tested as per DIN 408391, test
pulse 5 (load dump) limited to 58 V).
7)
The absolute voltage level must not drop below the specified minimum voltage.
8)
The load currents for the input capacitors are not taken into account.
9)
Core terminating sleeves are not required.
10)
Core terminating sleeves are not required.
