10 SPECIFICATIONS
Fig. 45: Adapter flange, clamping flange DIN32676 3"/DN65, suitable for PS= 10 bar
Fig. 46: Adapter flange, weldable, suitable for PS = 10 bar
Ø91
(3.58)
Ø12
(0.47)
All specifications in mm (inches)
Ø70
(2.75)
Ø12,3
(0.48)
All specifications in mm (inches)
