Single-axis Drive Amplifiers
NOTICE
Wrong flow direction of the coolant
→ For optimal cooling, consider the flow direction of the coolant during mounting. In-
stall the forward and return flow of the coolant according to the arrows [B].
For further information on the water cooling refer to chapter 11 “Water Cooling
(0362111OF/RF/SF)”, page 105.
The device is designed for vertical wall mounting. Other setup positions are possible but
you must consult SIEB & MEYER before.
42 Drive System SD2 - Hardware Description
