SIEB & MEYER SD2 Series User Manual

Power Supply Unit PS2
9.2.2 Technical Data
Device variant 0362190F
min. 3 × 110 V
AC
-20 %three-phase
max. 3 × 480 V
AC
+10 %
min. 1 × 110 V
AC
-20 %
Mains supply L1, L2, L3
(1)
single-phase
max. 1 × 230 V
AC
+20 %
up to 110 V
AC
6.2 kW
up to 230 V
AC
13 kW
Max. rated power
up to 480 V
AC
27 kW
Logic supply 18 to 28 V
DC
(max. 0.2 A at 24 V
DC
)
three-phase max. 3 × 40 AProtective fuse L1, L2, L3
single-phase max. 1 × 40 A
Ballast resistor up to 230 V
AC
, min. 10 Ω /
> 230 V
AC
min. 22 Ω
Max. heat sink temperature 75° C
Ambient temperature 0 to 40 °C without power reduction, max. 60 °C
Above 40 °C the power must be reduced by 1.5 % per 1 °C.
Humidity up to 85 % (without moisture condensation)
Capacity of DC link 495 µF
Max. weight 3.1 kg
(1)
For power chokes refer to Manufacturers.
Note
The rated power values are maximum values, that means they apply when optimum
cooling is provided by a heat sink.
88 Drive System SD2 - Hardware Description
