SIEB & MEYER SD2 Series User Manual

Single-axis Drive Amplifiers
6.6.2 Technical Data
Device variant 0362114xC
0362114xF
(1)
Current range DC EC IC DF EF IF
Rated current (8 kHz) Data not
available yet
20 A
p
/
14 A
rms
35 A
p
/
25 A
rms
Data not
available yet
20 A
p
/
14 A
rms
20 A
p
/
14 A
rms
Rated current (16 kHz) -- -- - -- 20 A
p
/
14.14 A
rms
--
Peak current of the output stage
(8 kHz)
20 A
p
40 A
p
80 A
p
20 A
p
40 A
p
80 A
p
Peak current of the output stage
(16 kHz)
-- -- - -- 40 A
p
--
Max. time for peak current 5 s 2 s 2 s 5 s 2 s 2 s
Max. temperature of the output
stage
75° C
Max. output frequency 2000 Hz
Output frequency stability ≤ 0.2 %
DC link voltage 40 to 325 V
DC
+10 % 40 to 680 V
DC
+10 %
Logic supply 18 to 28 V
DC
Power loss logic unit 12 W
Power loss of power unit Max. 5 % of the output motor power, at least 20 W
Overvoltage threshold 410 V
DC
850 V
DC
Undervoltage threshold 40 V
DC
Ambient temperature range 5 °C to 60 °C at a maximum relative humidity of 85 % (without moisture condensation),
100 % rated current up to max. 40 °C. At higher temper-
atures the power must be reduced by 1.5 % per 1 °C.
IP Code IP20
Max. weight 5.7 kg
(1)
The technical data for the device variants 0362114MF, 0362114NF and 0362114QF are to be found in separate chapters
(0362114MF/NF: see page 52; 0362114QF: see page 56).
48 Drive System SD2 - Hardware Description
