Technical Data AddFEM
4-10
AddFEM
C79000–G8076–C900–03
Analog Inputs (continued)
Measuring ranges of the current inputs /
overflow range
0...20 mA / –3.511 mA to 23.7 mA
4...20 mA / –1.185 mA to 22.96 mA
$20 mA / $23.7 mA
$30 mA / $35.55 mA
Measuring range of the voltage inputs
Only with the channels 1 to 6
0...10 V / –1.755 V to 11.85 V
"10 V / "11.85 V
Number and classification of the inputs 6 inputs measuring current, 6 inputs mea-
suring either current or voltage
Feedthrough between the channels at
Direct voltage
50 Hz
60 Hz
v 60 dB
v 60 dB
v 60 dB
Non–linearity t 0.01%
