Analog Outputs
Number of analog outputs 8
Greatest error at 25°C $0.15%
Temperature coefficient $100 ppm/K
Greatest error across the complete
temperature range
$0.4%
Digital resolution of the digital–analog
converter
13 bits + preceding sign
Value of the least significant bit (LSB) 8 µA
Total system transfer time interval
(TAQD +TAQT)
1ms
Transient recovery time at changes
across the entire range
0.6 ms
Overshoot 0.2%
Greatest temporary deviation during
each specified electrical disturbance
test
Refer to EMC data (Section 4.2)
Configuration of the terminals Refer to Appendix A, connector X4,
Page A-1
Permissible inductive load 1 H
Shutdown cycles of the power supply Up to 10 ms a buffer overrides.
In case of longer failures the starting
operation depends on the software
Conversion process Parallel conversion of all 8 output
channels
Power output range unipolar / over-
flow range / load impedance
0...20 mA/$23.5 mA/500 Ω
4...20 mA/–4.96 to +22.96 mA/500 Ω
Power output range bipolar / overflow
range / load impedance
"20 mA/"23.5 mA/500 Ω
"30 mA/"35.55mA/300 Ω
Power output bipolar (only channels 1
to 4)
1)
"50 mA/"59.26 mA/180 Ω
Monitoring tolerance of the output cur-
rent
4%
Feedthrough between the channels
at:
Direct voltage
50 Hz
60 Hz
v 60 dB
v 60 dB
v 60 dB
Non–linearity t 0.1%
Output ripple t 0.1%
1)
The analog outputs 1 to 4 are limited to a mean load of 40 mA in order to
protect the module. The extension of the current range of these outputs to 50
mA / 59.26 mA is only intended for controlling integral–action actuating ele-
ments. To this purpose a max. current of 59.26 mA is provided for a limited
period.
The current is monitored by software and is limited as follows:
Mean–value limitation: At a power output configured to "50 mA a first–order
time delay with a time constant of 10 seconds is used to form the mean value
of the output current. It the mean value exceeds a current of 40 mA, the out-
put current and thus also the mean value of the output current is limited to
"40 mA.
