Technical Data AddFEM
4-16
AddFEM
C79000–G8076–C900–03
Climatic Conditions
Temperature (ambient temperature)
Operation
Storage/transportation
(packed for dispatch)
Tested to DIN EN 60068–2–1, DIN EN 60068–2–2, UL 508
and DIN EN 61131–2:
0
o
C to +50
o
C At nominal load (refer to Section 4.1)
0
o
C to +55
o
C At nominal load. However max. of 200 mA
possible at digital outputs 5, 6, 7, 8 as well
as 13, 14, 15 and 16
0
o
C to +60
o
C At nominal load. However, max. of 120
mA
11 possible at digital outputs 3 to 8 and 11
to 16. Max. input voltage at the binary
inputs $28 V. PROFIBUS normal
operation without load of the additional
PROFIBUS supply for 90 mA (i.e. no
users without own supply, e.g. optical
fiber converter, connectable).
Maximum temperature gradient 10°C/hour
Tested to DIN EN 60068-2-1 and DIN EN 60068-2-2:
–40
o
C to +70
o
C
Maximum temperature gradient 5°C/hour
(Danger of moisture condensation at higher temperature gra-
dients. Moisture condensation is not allowed).
In case of long–term storage it is advisable to take the modu-
les into operation for an hour each at regular intervals in order
to form the electrolytic capacitors:
At a storage temperature of up to 40°C: Within the first 10
years every 5 years, afterwards every 3 years.
At a storage temperature over 40°C: Every 2 years.
Relative humidity
Operation
Storage/transportation
(packed for dispatch)
Max. 95% at + 25
o
C. Moisture condensation is not allowed.
Corresponds to RH degree of stress 2 to IEC 61131–2.
Tested to IEC 60068–2–3: 95% at 30
o
C
Max. 95% at + 25
o
C. Moisture condensation is not allowed.
Tested to IEC 60068–2–30: 95% at 25
o
C to 55
o
C
Air pressure Storage: 1080...660 hPa (–1000 to + 3500 m)
Operation: 1080...900 hPa (–1000 to + 1000 m)
At greater heights the cooling decreases so that the upper
operating temperature has to be reduced. (Reference value:
10 K/1000 m height as from 1000 m above mean sea level).
Pollutant concentration S0
2
< 0.5 ppm, rel. humidity < 60%, no condensation
H
2
S < 0.1 ppm, rel. humidity < 60%, no condensation
Mechanical Ambient Conditions
Vibration
In operation, mounted by means
of screw fixing device or on DIN
rails (see Section 5.1)
Packed for dispatch
Tested to DIN EN 60068-2-6:
10 to 58 Hz: Amplitude 0.075 mm
58 to 500 Hz: Acceleration 1 g (10 m/s
2
)
Excitation signal: Sliding sine
Frequency modification speed: 1 octave/min,
10 cycles per axis
Tested to DIN EN 60068-2-6:
5 to 8.5 Hz: Amplitude 3.5 mm
8.5 to 500 Hz: Acceleration 1 g (10 m/s
2
)
Excitation signal: Sliding sine
Frequency modification speed: 1 octave/min
10 cycles per axis
