Siemens CU240S DP-F User Manual

Commissioning (software)
5.7 Commissioning modes
Control Units CU240S
Operating Instructions, 11/2006, A5E00766042B AA
5-51
Removing the MMC
To remove the MMC from the Control Unit, the following procedure should be performed:
1. Using a thin-bladed screwdriver, push down the release-catch on the MMC housing.
2. Grasp the MMC gently and pull upwards.
This procedure is shown in the figure below.
6,1$0,&6
6,1$0,&6
Figure 5-11 Removing the MMC from the Control Unit
