Page #124 background image
Commissioning (software)
5.8 Commissioning the Fail-safe Functions
Control Units CU240S
5-68 Operating Instructions, 11/2006, A5E00766042B AA
5.8.5 Common step-by-step descriptions for fail-safe functions
Change password
Parameter Description Unit Default Min. Max.
P9761 SI input password
The safety password is entered in this parameter to get access to
change the fail-safe parameters.
- 0 1000 99999
P9762 SI change password
Enter the new password. The password must have 5 digits but no
leading zero (0).
- 0 1000 99999
P9763 SI change password confirmation
The new password must be confirmed here. If P9762 and P9763 are
the same, then this value is written into r9760. In the future, fail-safe
parameters can be accessed by entering this password into P9761.
- 0 1000 99999
Enabling fail-safe functions
Parameter Description Unit Default Min. Max.
P9601 = ? SI enable parameter
Fail-safe parameter for enabling the individual fail-safe control
functions.
Bit 00 = 1/0: Reserved
Bit 01 = 1/0: Activation/deactivation of the forced dynamisation after
STO
- 2 0 2
P9801 = ? SI enable parameter
Refer to P9601
- 2 0 2
Enable fail-safe brake monitoring
Parameter Description Unit Default Min. Max.
P9602 = ? SI enable safe brake monitoring
0: Disable monitoring of safe brake control
1: Enable monitoring of safe brake control
- 0 0 1
P9802 = ? SI enable safe brake monitoring
Refer to P9602
- 0 0 1
