Description
3.5 Interfaces of the CU240S variants
Control Units CU240S
3-10 Operating Instructions, 11/2006, A5E00766042B AA
3.5 Interfaces of the CU240S variants
Overview
Table 3-2 Following interfaces are available, see also figure "Variants of Control Units CU240S"
CU240S CU240S DP CU240S DP-F
MMC slot x x x
Option port x x x
Terminals x x x
General I/O DIP switches x x x
PROFIBUS DP DIP switches -- x x
Status LEDs x x x
Power module interface (PM-IF) x x x
SUB-D connector (RS485 or PROFIBUS) x x x
MMC
The Multi Media Card (MMC) is a small, removable flash storage device, with a low power
consumption which provides the ability to store data sets for the inverter.
The MMC provides non volatile data storage which requires no power to maintain the data
stored on the card.
It is recommended that the SINAMICS-MMC (order number: 6SL3254-0AM00-0AA0) is used
for the storage and transfer of data sets.
Option port
Via the Option port the OP is connected to the inverter, it can also be used to connect a PC
via the PC Connection Kit to the inverter for parameterizing using STARTER.
Terminals
Table 3-3 Control terminals
Terminal Designation Function CU240S/
CU240S DP
CU240S DP-F
1 +10V OUT Non-isolated output +10 V, max. 10 mA x x
2 0V OUT Supply reference (terminal 1) x x
3 AI0+ Analog input 0 positive x x
4 AI0- Analog input 0 negative x x
5 DI0 Digital input 0, isolated x x
6 DI1 Digital input 1, isolated x x
7 DI2 Digital input 2, isolated x x
8 DI3 Digital input 3, isolated x x
