Commissioning (software)
5.6 Parameterization with STARTER
Control Units CU240S
5-16 Operating Instructions, 11/2006, A5E00766042B AA
5.6 Parameterization with STARTER
Commissioning with STARTER
The following interfaces - which are Control Unit dependent available:
Table 5-15 Connection possibilities for STARTER
Type USS on RS232 USS on RS485 PROFIBUS DP
PC connected to CU
via
PC Connection Kit Sub D cable & RS485 to
RS232 converter
DP interface
Interface Option port Sub D connector Sub D connector
Restrictions Peer to peer Peer to peer up to 125 slaves
CU240S X X --
CU240S DP X -- X
CU240S DP-F X -- X
General information for connecting STARTER
USS address: see P2011, default setting P2011 = 0
USS baudrate: see P2010, default setting P2010 = 8 (≙ 38400 baud)
PROFIBUS DP address: see P0918 or PROFIBUS DP DIP switches.
STARTER projects
Using STARTER either a new project can be created or an already existing project can be
opened.
To create a new project in STARTER one of the following methods can be used:
● Search inverter
● Wizard
● Select inverter.
When opening an existing project or creating a new project STARTER is in the offline mode.
To go online the button
has to be pressed.
Changing parameters with STARTER
Parameters can be changed online or offline (online preferred).
Online parameter changes are stored in the RAM of the inverter. A manual transfer from
RAM to EEPROM can be triggered by pressing
. When closing STARTER and the
contents of the RAM and EEPROM are different, the user is asked whether or not they wish
to transfer the RAM data to the EEPROM.
