Commissioning (software)
5.9 Commissioning with PROFIBUS DP
Control Units CU240S
5-86 Operating Instructions, 11/2006, A5E00766042B AA
Address Function
9 E 1.0 SLS bit from inverter
Table 5-25 Output addresses for PROFIsafe signals
Address Function
1 A 0.0 STO bit to inverter
2 A 0.1 SS1 bit to inverter
…
9 A 1.0 SLS to from inverter
5.9.7 Switch over behavior of Communication telegram
Overview
Table 5-26 Switch over behavior of telegram structures, Part 1
P0922 = 1 → 20 1 → 350 1 → 352 1 → 999
if
P0700 ≠ 6
if
P0700 = 6
if
P0700 ≠ 6
if
P0700 = 6
if
P0700 ≠ 6
if
P0700 = 6
if
P0700 ≠ 6
if
P0700 = 6
P0820 = 2032.15 2091.15 unchanged 2091.4 unchanged unchanged unchanged unchanged
P0821 = unchanged unchanged unchanged 2091.5 unchanged unchanged unchanged unchanged
P1035 = 19.13 19.13 unchanged 2090.13 unchanged 2090.13 unchanged unchanged
P1036 = 19.14 19.14 unchanged 2090.14 unchanged 2090.14 unchanged unchanged
Table 5-27 Switch over behavior of telegram structures, Part 2
P0922 = 20 → 1 20 → 350 20 → 352 20 → 999
if
P0700 ≠ 6
if
P0700 = 6
if
P0700 ≠ 6
if
P0700 = 6
if
P0700 ≠ 6
if
P0700 = 6
if
P0700 ≠ 6
if
P0700 = 6
P0820 = 0.0 0.0 unchanged 2091.4 0.0 0.0 unchanged unchanged
P0821 = unchanged unchanged unchanged 2091.5 unchanged unchanged unchanged unchanged
P1035 = unchanged 2090.13 unchanged 2090.13 unchanged 2090.13 unchanged unchanged
P1036 = unchanged 2090.14 unchanged 2090.14 unchanged 2090.14 unchanged unchanged
