Siemens CU240S DP-F User Manual

Description
3.6 Factory settings of the CU240S control units
Control Units CU240S
3-16 Operating Instructions, 11/2006, A5E00766042B AA
3.6 Factory settings of the CU240S control units
Factory Settings for command and setpoint source
P0700 = 0 is the same as P0700 = 2 or 6 dependend on type of Control Unit.
Note
Setting P0700 = 6 (command source via fieldbus communication) and P1000 = 6 (setpoint
source via fieldbus communication) are not possible with a CU240S
Setting P0700 = 5 (command source via USS communication) and P1000 = 5 (setpoint
source via USS communication) are not possible with a CU240S DP or a CU240S DP-F
Table 3-6 Function Selection of Digital Input and Digital Output
CU240S CU240S DP, CU240S DP-F
Parameter
P0700 = 2 P0700 = 6
P0701 1 0 0
P0702 12 0 0
P0703 9 9 9
P0704 15 15 15
P0705 16 16 16
P0706 17 17 17
P0707 18 18 ---
P0708 0 0 ---
P0709 0 0 ---
P0731 52.3 52.3 52.3
P0732 52.7 52.7 52.7
P0733 0.0 0.0 0.0
