5.2 Parameters
Control Units CU240S
5-4 Operating Instructions, 11/2006, A5E00766042B AA
5.2.3 Parameter Attributes
Overview
In the Parameter List, the header line of each parameter shows all the attributes and groups
for that specific parameter. The figure below shows the details for parameter P0700 and
r1515.
%,&2LIH[LVW
&86'3
&86'3)
6HOFWLRQRIFRPPDQGVRXUFH&RPPDQGVRXUFHVH
6HOFWLRQRIFRPPDQGVRXUFH&RPPDQGVRXUFHVH
$FFHVVOHYHO
4XLFNFRPP12
&DQEHFKDQJHG7
0LQ

3*URXS&RPPDQGV
$FWLY<(6
8QLW
0D[

'DWDW\SH8QVLJQHG
'DWDVHW&'6
)DFWRU\VHWWLQJ

3>@
3>@
,QGH[
&830YDULDQWV
Figure 5-2 Description of attributes for parameter P0700
%,&2LIH[LVW
*
&2$GGLWLRQDOWRUTXHVHWSRLQW&2$GGWUTVHW
&2$GGLWLRQDOWRUTXHVHWSRLQW&2$GGWUTVHW
$FFHVVOHYHO 3*URXS&ORVHGORRSFRQWURO
8QLW
'DWDW\SH)ORDWLQJ3RLQW
U
U
Figure 5-3 Description of attributes for parameter r1515
Index
Using the index, a parameter (e.g. p0013[20]) is defined with several consecutive elements
(in this case, 20). Each individual index is defined using a numerical value.
When transferred to a parameter this means that an indexed parameter can have several
values. The values are addressed using the parameter number including the index value
(e.g. p0013[0], p0013[1], p0013[2], p0013[3], p0013[4], ...).
Indexed parameters are used, for example:
● Drive Data Sets (DDS)
● Command Data Sets (CDS)
● Sub functions.
