Commissioning (software)
5.7 Commissioning modes
Control Units CU240S
5-50 Operating Instructions, 11/2006, A5E00766042B AA
5.7.4.3 Inserting and removing the MMC
Inserting the MMC
To insert an MMC into the Control Unit of the inverter, the process shown in the figure below
should be performed.
6,1$0,&6
6,1$0,&6
Figure 5-10 Installing the MultiMedia Card (MMC)
Warning
When inserting an MMC during operation Alarm A0564 appears if P8458 is set to 0. This is a
hint that with P8456 = 0 no automatic download will be performed at startup.
If the MMC is inserted to perform an upload this alarm can be quitted without any further
action.
If the MMC is inserted to perform an automatic download P8456 must be set accordingly.
