Page #103 background image
Commissioning (software)
5.7 Commissioning modes
Control Units CU240S
Operating Instructions, 11/2006, A5E00766042B AA
5-47
5.7.4.1 Series commissioning with the OP
Upload and download a parameter set with an OP
With an OP a single parameter set can be uploaded from an inverter and then downloaded
into another inverter.
To copy a parameter set from one inverter to another, the following procedure should be
performed.
Upload a parameter set with an OP
Prerequisites
An inverter with an apropriate parameter set is available (upload inverter)
Supply voltage is active for the upload inverter
The upload inverter is in "Ready State".
Parameter Description (Parameter name and factory setting (if not variable) in bold) Setting
Fit the OP to the Inverter - for the parameter set to be uploaded, perform the following steps:
P0003 = 3 User access level*
1: Standard: Allows access into most frequently used parameters
2: Extended: Allows extended access e.g. to inverter I/O functions
3: Expert: For expert use only
P0010 = 30 Commissioning parameter*
0: Ready
1: Quick commissioning
2: Inverter
30: Factory setting, parameter transfer
95: Safety commissioning (for CUs with fail-safe functions only)
P0802 = 1 Transfer data from EEPROM
0: Disabled
1: Start OP transfer
2: Start MMC Transfer
While the upload is active "bUSY" will be displayed on the OP and the inverter will not react to
any commands.
If the upload has been completed successfully, P0010 and P0802 will be set to 0 and the OP
display will return to normal.
If the upload has failed, F00055 (failure while saving parameter on OP) or F00057 (OP fault)
will be displayed.
In this case attempt another upload.
After a successful upload disconnect the OP from the upload inverter.
