Description
3.6 Factory settings of the CU240S control units
Control Units CU240S
Operating Instructions, 11/2006, A5E00766042B AA
3-17
Table 3-7 BICO Command Parameter
CU240S CU240S DP, CU240S DP-F
Parameter
P0700 = 2 P0700 = 6
P0840 722.0 2090.0
P0842 0.0 0.0
P0844 1.0 2090.1
P0845 19.1 19.1
P0848 1.0 2090.2
P0849 1.0 1.0
P0852 1.0 2090.3
Table 3-8 Command Sources for Fixed Frequencies
CU240S CU240S DP, CU240S DP-F
Parameter
P0700 = 2 P0700 = 6
P1020 722.3 722.3
P1021 722.4 722.4
P1022 722.5 722.5
P1023 722.6 722.6 (0.0 for CU240S DP-F)
Table 3-9 Faults, Alarms, Monitoring
CU240S CU240S DP, CU240S DP-F
Parameter
P0700 = 2 P0700 = 6
P2103 722.2 722.2
P2104 0.0 2090.7
P2106 1.0 1.0
Factory Settings for Setpoint Source
CU240S CU240S DP, CU240S DP-F Source
P1000 = 2 P1000 = 6
Frequency setpoint Analog setpoint (P0754 [%]) Fieldbus (P2050.1 [Hex])
