Commissioning (software)
5.7 Commissioning modes
Control Units CU240S
5-60 Operating Instructions, 11/2006, A5E00766042B AA
Warning
Fail-safe parameters
When using Standard CUs, only the factory reset with P0970 = 1 must be taken into
account.
When using CUs with fail-safe functions two reset methods are available:
• P0970 = 1 resets only non fail-safe function relating parameters (application
parameters).
If a factory reset with P0970 =1 is performed on a Control Unit with fail-safe functions
all application parameters will be reset, previous parameters settings regarding fail-
safe functions remain unchanged. This means, no acceptance test has to be
performed.
• P0970 = 10 (password protected) resets only fail-safe function relating parameters
If parameters regarding fail-safe functions must be changed, an acceptance test has
to be performed.
Reset to the factory setting
Parameter or action Description (Parameter name and factory setting (if not variable) in bold)
P0003 = 1 User access level*
1: Standard: Allows access into most frequently used parameters.
P0004 = 0 Parameter filter
0: All parameters
P0010 = 30 Commissioning parameter*
30: Factory setting, parameter transfer
P0970 = 1 Factory reset*
1: Parameter reset to the default values
BUSY (on OP)
Progress bar (STARTER)
The inverter carries-out a parameter reset (duration, approx. 10 s) and then automatically
exits the reset menu and sets
P0970 = 0: Disabled
P0010 = 0: Ready
Note
The following parameters will not be changed with a factory reset:
• P0014 Store mode
• P0100 Europe / North America
• P0201 power stack code number
• Communication parameters (USS and PROFIBUS settings)
• Data depending on actual Power module
