Commissioning (software)
5.9 Commissioning with PROFIBUS DP
Control Units CU240S
Operating Instructions, 11/2006, A5E00766042B AA
5-91
Bit Value Meaning Remarks
0 Coast Stop activated Coast Stop (OFF 2) command is present.
1 Quick Stop not activated -- 5
0 Quick Stop activated Quick Stop (OFF 3) command is present.
1 Switching on inhibited The drive goes only again in the "Switched On" condition
with "No Coast Stop AND No Quick Stop" followed by "ON".
6
0 Switching on not inhibit --
1 Warning present Drive still works; warning in the service/maintenance para-
meter; no acknowledgement, see alarm parameter r2110.
7
0 No warning There is no warning or the warning has disappeared again.
1 Speed error within tolerance range Setpoint/actual value deviation within tolerance range. 8
0 Speed error out of tolerance range --
1 Master control requested The automation system is requested to assume control. 9
0 No control requested The master is not currently the master control.
1 Maximum frequency reached or
exceeded
Inverter output frequency is higher or equal to the maximum
frequency.
10
0 Maximum frequency not reached --
1 -- -- 11
0 Warning: Motor at current/torque limit --
1 Motor holding brake active Signal can be used to control a holding brake. 12
0 -- --
1 -- Motor data indicate overload condition. 13
0 Motor overload --
1 CW rotation -- 14
0 CCW rotation --
1 -- -- 15
0 Inverter overload e.g. current or temperature.
