Functions
8.1 BICO Technology
Control Units CU240S
8-2 Operating Instructions, 11/2006, A5E00766042B AA
The following internal or external sources or interfaces can be selected for the frequency
setpoint source P1000. In addition to the main setpoint (second position), a supplementary
setpoint (first position) can be selected. This is shown in the table below.
Table 8-2 Parameter P1000
Significance
Parameter Values
Main setpoint source Supplementary setpoint source
0 No main setpoint --
1 MOP setpoint (motorized potentiometer) --
2 Analog setpoint --
3 Fixed frequency --
4 USS on RS232 --
5 USS on RS485 --
6 Fieldbus --
7 Analog setpoint 2 --
10 No main setpoint MOP setpoint
11 MOP setpoint MOP setpoint
12 Analog setpoint MOP setpoint
… … …
77 Analog setpoint 2 Analog setpoint 2
Note
The complete list of all the possible settings is contained within Parameter Manual (see
P1000).
The selection of the command source is made independently of the selection of the
frequency setpoint source. This means that the source to enter the setpoint does not have to
match the source to enter the power-on/power-off command (command source). This
means, for example, that the frequency setpoint P1000 = 6 can be connected using an
external device and ON/OFF is entered using digital inputs DI (terminals, P0700 = 2).
Caution
When P0700 or P1000 are modified, then the frequency inverter also changes the
subordinate BICO parameters (refer to the Parameter Manual for P0700 or P1000 in the
appropriate tables).
There is no prioritization (priority assignment) between direct BICO parameterization and
P0700/P1000. The last modification is valid.
