Functions
8.11 JOG
Control Units CU240S
Operating Instructions, 11/2006, A5E00766042B AA
8-51
Pressing the appropriate key accelerates the motor to the frequency in P1058 (JOG right) or
P1059 (JOG left) at the ramp rate set in P1060. When the key is released, the motor stops,
decelerating at the rate set in P1061. If JOG right and JOG left signals are given at the same
time, there is no reaction, and a warning A0923 is raised. Internal BICO connections may
also be used to select other settings and control methods.
Example
Command source via "USS RS232" interface (using the PC connection kit on the option port)
Standard method P0700 = 4
P1055 = 2032.8
P1056 = 2032.9
BICO method
…
(for a complete list refer to Parameter List P0700)
Note
The JOG fuction as used in the SINAMICS G120 inverter does not correspond to the
definition in PROFIdrive profile.
