Functions
8.13 Setpoint channel
Control Units CU240S
8-68 Operating Instructions, 11/2006, A5E00766042B AA
Table 8-27 Possible settings for parameters P0700 and P1000
Value Command source (P0700) Value Setpoint source (P1000)
1 OP (keyboard) 1 MOP setpoint
2 Terminal strip 2 Analog setpoint
4 USS on RS232 3 Fixed frequency
5 USS on RS485 4 USS on RS232
6 Fieldbus 5 USS on RS485
6 Fieldbus
7 Analog setpoint 2
10 No main setpoint + MOP setpoint
…
77 Analog setpoint 2 + analog setpoint 2
