Commissioning (software)
5.7 Commissioning modes
Control Units CU240S
5-32 Operating Instructions, 11/2006, A5E00766042B AA
General settings
Parameter Description (Parameter name and factory setting (if not variable) in bold) Setting
P0003 = 3 User access level*
1: Standard: Allows access into most frequently used parameters.
2: Extended: Allows extended access e.g. to inverter I/O functions
3: Expert: For expert use only
P0210 = ? Supply voltage (enter the voltage in V)
This parameter enters the real line supply voltage to which the Inverter is connected. Only
necessary if P1254 = 0 (default: P1254 = 1).
P0290 = 2 Inverter overload reaction
This defines the response of the Inverter to an internal overtemperature.
0: Reduce output frequency
1: Trip (F0004)
2: Reduce pulse frequency and output frequency
3: Reduce pusle frequency then trip (F0004)
P0335 = 0 Motor cooling (enter the motor cooling system)
0: Self-cooled using the shaft mounted fan attached to the motor
1: Force-cooled using the separately powered cooling fan
2: Self-cooled and internal fan
3: Force-cooled and internal fan
Pulse Encoder
Parameter Description (Parameter name and factory setting (if not variable) in bold) Setting
P0400 = 0
or
P0400 = ?
Select encoder type *
0: Disabled (no encoder fitted)
2 or 12: Two quadrature encoder (two channels)
P0408 = ? Number of encoder pulses (Only if encoder is fitted)
Enter the number of encoder pulses per revolution. The number of encoder pulses per
revolution P0408 is limited by the maximum pulse frequency of the pulse encoder module
(f
max
= 300 kHz)
