Communications configuring
System- and communication configuring D7-SYS - SIMADYN D 3-111
Edition 12.2003
Communications reference : Type: Cyclic server
Association type : MSZY Local LSAP :
Remote address : Remote LSAP :
Max. PDU length : 241
Supported utility :
Read : .ind Write : .ind
Name :
Table 3-49 Mask, "Cyclic server"
Rules:
• The communications reference is as required within the framework of
the general rules.
• Local LSAP must coincide with the "Remote LSAP" of the remote
client.
• The remote address and remote LSAP can be entered, defined, but
then only the appropriately selected client can establish a connection
(access protection!); or both values can be set to 255, and then the
association is open for all.
Features:
Cyclic data transfer with slaves
• SIMADYN D is exclusively client.
• An association must be configured for each object which SIMADYN D
accesses in the remote server.
• SIMADYN D establishes the connection and initiates data transfer.
• The object, which SIMADYN D accesses in the remote server is
defined by appropriate CFC configuring (address stage 2 at the
address input).
Application:
• Process data, with SIMADYN D as client.
Cyclic client
