Communications configuring
3-120 System- and communication configuring D7-SYS - SIMADYN D
Edition 12.2003
Communications reference : 2
Type
:
Non-cyclic client
Association type : MMAZ Local LSAP : 10
Remote address : 2 Remote LSAP : 12
Max. PDU length : 241 Monitoring interval : 0 s
Password : 0 Group : 0
Profile : 0
Supported utilities :
Read : No Write : .req
Get OV (detailed version) : .req Information report : No
Symbolic addressing : .req
Max. number of parallel tasks:
Transmitting : 1 Receiving : 0
Name : CLI WRITE 2
Table 3-54 Mask, "Non-cyclic client"
Explanations:
• Station 1 is the client so that the "Non-cyclic client" mask is selected
here.
• "Communications reference" 2 corresponds to the data entry made in
address stage 1 at input AT of the SIMADYN D transmit block.
• The "Association type" is non-cyclic, master-master, as both stations
(SIMADYN D) are master.
• "Local LSAP", "Remote address" and "Remote LSAP" define the
communications path between the two stations.
• The default values were used for the fields "Max. PDU length",
"Monitoring interval", "Password", "Group", "Profile".
• The "Get OV (detailed version)" and "Write" utilities are supported and
more specifically as requester. A client is always a requester as far as
this utility is concerned.
− "Write" must be supported, because the transmit function block is
appropriately configured.
Station 1,
communication
association 2:
