Communications configuring
System- and communication configuring D7-SYS - SIMADYN D 3-121
Edition 12.2003
− "Get OV (detailed version)" is supported, because the SIMADYN D
communications partner always supports this utility as server thus
achieving a high degree of data security.
− "Symb. addressing" does not have to be supported here as the
object is accessed per index (6001).
• The "Max. number of parallel transmit tasks" is equal to "1", because
precisely one (write) task is defined by the SIMADYN D software.
Communications reference : 2 Type: Non-cyclic server
Association type : MMAZ Local LSAP : 12
Remote address : 1 Remote LSAP : 10
Max. PDU length : 241 Monitoring interval : 0 s
Supported utilities :
Read : .ind Write : .ind
Get OV (detailed version) : .ind Information report : No
Symb. addressing : .ind
Max. number of parallel tasks:
Transmitting : 0 Receiving : 1
Name : SERV 1
Table 3-55 Mask, "Non-cyclic server"
Explanations:
• Station 2 is server thus, the "Non-cyclic server" mask is selected here.
• The "Communications reference" data for the server has absolutely no
reference to the CFC configuring, and, within certain limits, can be
freely-selected.
• "Local LSAP", "Remote address" and "Remote LSAP" must
correspond to the data entered for station 1.
• For the remaining fields, the default values were selected, and the
values are permanently assigned.
Station 2,
communications
association 2:
