Changeover from STRUC V4.x to D7-SYS
4-10 System- and communication configuring D7-SYS - SIMADYN D
Edition 03.2001
STRUC
V.4.x
CFC with D7-
SYS
Pre-
assignment
*(‘---‘ = 0)
Comment
CTB4 - --- Eliminated; replaced by NOP8_D
CTBF - --- Eliminated; replaced by NOP8
@TCI @TCI CHA = 200 ---
@TRI @TRI --- ---
TRCC2 TRCC_I --- X as "INT" (previously "N2")
TRCC4 TRCC_D --- X as "DINT" (previously "N4")
TRCCF TRCC --- ---
@TCP @TCP CHA = 200 ---
TRHI TRHI --- ---
TRP1 TRP_B --- ---
TRP2 TRP_I --- X as "INT" (previously "N2")
TRP4 TRP_D --- X as "DINT" (previously "N4")
TRPF TRP --- ---
@DIS0R - --- Eliminated; replaced by @DIS
@DIS0T - --- Eliminated; replaced by @DIS
- @DIS --- New;
DISA1 - --- Eliminated; replaced by DISA_B
DISA2 - --- Eliminated; replaced by DISA_I
and DISA_W
DISA4 - --- Eliminated; replaced by DISA_D
DISAF - ---
Eliminated; replaced by DISA and
DISA_T
- DISA_I --- New;
- DISA_B --- New;
- DISA_D --- New;
- DISA --- New;
- DISA_T --- New;
- DISA_W --- New;
DISS1 - --- Eliminated; replaced by DISS_B
DISS2 - --- Eliminated; replaced by DISS_I
and DISS_W
DISS4 - --- Eliminated; replaced by DISS_D
DISSF - --- Eliminated; replaced by DISS and
DISS_T
- DISS_I --- New;
- DISS_B --- New;
- DISS_D --- New;
- DISS --- New;
- DISS_T --- New;
- DISS_W --- New;
DISA11 DISA1B --- ---
