Changeover from STRUC V4.x to D7-SYS
System- and communication configuring D7-SYS - SIMADYN D 4-11
Edition 03.2001
STRUC
V.4.x
CFC with D7-
SYS
Pre-
assignment
*(‘---‘ = 0)
Comment
DISA18 - --- Eliminated; not replaced
DISS11 DISS1B --- ---
DISS18 - --- Eliminated; not replaced
@DPH @DPH
UP = 1;
PHL = 1;
XWS, YWS, SPS as "INT"
(previously "N2");
XWL, YWL, SPL as "DINT"
(previously "N4")
DPI DPI --- XS, YS as "INT" (previously
"N2");
XL, YL as "DINT" (previously
"N4")
SER SER LT = 242 ---
RTCM RTCM
XYR = 97
XMO = 1
XDA = 1
---
RTC003 RTCABS --- ---
RTC005 RTCREL --- ---
@NMC @NMC --- ---
NRI NRI --- ---
NTC NTC --- ---
NTD NTD --- ---
NSI NSI --- ---
NSL NSL --- ---
@CSL2A @CSL2A
MAA = 1;
BDR = 3
---
@SYL2A @SYL2A
SEL = 1;
CNX = 1
---
DIAL2A DIAL2A
ST1 = 3;
ST2 = 3
---
@CPN @CPN --- ---
@CMM @CMM --- ---
@CEP @CEP --- ---
@CEP22 - --- Eliminated; replaced by @CEP
@CS1 @CS1 --- ---
@CS11 - --- Eliminated; replaced by @CS1
@CS2 @CS2 --- ---
@CS21 - --- Eliminated; replaced by @CS2
@CSH11 @CSH11 --- ---
@CSL2F @CSL2F MAA = 1;
BDR = 3
---
@CSL2L @CSL2L MAA = 1;
BDR = 3;
AST = 1
---
@CSL2D - --- Eliminated; replaced by @CSL2A
