Changeover from STRUC V4.x to D7-SYS
4-12 System- and communication configuring D7-SYS - SIMADYN D
Edition 03.2001
STRUC
V.4.x
CFC with D7-
SYS
Pre-
assignment
*(‘---‘ = 0)
Comment
@CSD01 @CSD01
BDR = 9600;
TWU = 64
---
@CSD02 @CSD02 BDR = 9600;
TWU = 64
---
@CSD03 @CSD03 BDR = 9600 ---
@CSD07 @CSD07 BDR = 9600 ---
@CSU @CSU BDR = 9600; ---
- @DRIVE PCF=1
PTF=1
PEN=1
New;
- PNAME New;
- PLIM MIN=-1.0e38;
MAX=1.0e38
New;
-PLIM_I
MIN=-32768;
MAX=32767
New;
-PLIM_D
MIN=-
2147483648;
MAX=2147483
647
New;
-PLIM_T
MIN=0.0ms;
MAX=1.0e38m
s
New;
- PTRANS --- New;
- CBCONF --- New;
- TFAW --- New;
- RFAW --- New;
- SYNCT4 --- New;
- @PEER BDR = 6 New;
- @USS_S BDR = 6;
PAR = 1
PZD = 2
CNX = 10
New;
- @USS_M BDR = 6; New;
* Corresponds to „0“ as pre-assignment of the various parameters of the
individual function blocks.
Table 4-8 Changes in the communication blocks
