Closed-loop thyristor current control
5-72 System- and communication configuring D7-SYS - SIMADYN D
Edition 06.2002
Connection 1:1
Pair No.
Contact assignment
Z
2
is cable, 4) is shield connection
Core A Core B
1d4b4
2d6b6
3d8b8
4 d10 b10
5 d12 b12
6 d14 b14
7 d20 b20
8 d22 b22
9 d24 b24
10 d26 b26
11 d28 b28
12 d30 b30
13 Not assigned
(contact Z
2
with contact Z
2
)
1) 2 x shell-type enclosure A with catches:
Order No.:A09060480501 GDS A-FL
Manufacturer: Harting
2) 2 x insulating bodies for crimp connection:
Order No.:A09060483201 (48 pin)
Manufacturer: Harting
3) Control cable 13 x 2 x 0.18:
Order No.:6FC9343-0AC
Manufacturer: Siemens
4) 2 x cable LIY 1 x 0.5 / 1.6 ws:
(shield connection)
5) Spring-mounted contacts to crimp:
Order No.:09060006421 Crimp
Manufacturer: Harting
Connecting cable,
firing pulses (X1)
