Closed-loop thyristor current control
System- and communication configuring D7-SYS - SIMADYN D 5-73
Edition 06.2002
Connection 1:1
Pair No.
Contact assignment
(Z
2
is cable, 4) is shield connection)
Core A Core B
1b4z4
2b8z8
3 b12 z12
(b14) (z14)
4 b16 z16
5 b18 z18
6 b20 z20
7 b22 z22
8 b24 z24
9 b28 z28
10 b30 z30
(contact Z
2
with contact Z
2
)
Connection b14/z14 only for current actual value sensing in a V circuit
configuration
1)
2 x shell-type enclosure A with catches:
Order No.:A09060480501 GDS A-FL
Manufacturer: Harting
2) 2 x insulating bodies for crimp connection
Order No.:A09060483201 (48 pin)
Manufacturer: Harting
3) Control cable 10 x 2 x 0.18 – W -:
Order No.:6FC9343-0AB
Manufacturer: Siemens
4) 2 x cable LIY 1 x 0.5 / 1.6 ws:
shield connection
5) Spring-mounted contacts to crimp:
Order No.:09060006421 Crimp
Manufacturer: Harting
Connecting cable,
actual values (X2)
