Communications configuring
3-4 System- and communication configuring D7-SYS - SIMADYN D
Edition 12.2003
Used for the
communications
partner
• SIMADYN D
• SIMATIC S5/S7
• Third-party systems
• COROS
Hardware required
• CSH11 communications module
Communication
utility
• Layer 2: Process data
• Layer 4: Process data, message system
• Layer 7: (STF): Process data and message system
Central coupling
block
• @CSH11
Features
• Standardized bus according to Ethernet (IEEE 802.3)
• A maximum of 1024 nodes can be coupled
• Baud rate: 10 Mbaud
• The SINEC system time can be input
• The bus can be parameterized using the NML
software
Table 3-4 Industrial Ethernet coupling (SINEC H1)
Used for the
communications
partner
• SIMATIC S5/S7
• SIMOVERT/SIMOREG drive converters
• ET200
• SIMADYN D
• Certified third-party equipment/devices
Hardware required
• CS7 communications module with SS52
communications module
Communications
utility
• Process data
• Parameter processing
Central coupling
block
• @CSPRO
Features
• Standardized multi-master bus for communications
between SIMADYN D and a maximum of 123
communication partners
• Master slave principle (CS7/SS52 is master and/or
slave)
• PROFIBUS standard according to EN 50170
• Fast
• Max. 12 Mbaud
• Maximum net data length, 244 bytes
• Bus is parameterized using the COM PROFIBUS
software
Table 3-5 PROFIBUS DP coupling
Industrial Ethernet
(SINEC H1)
PROFIBUS DP
