Communications configuring
System- and communication configuring D7-SYS - SIMADYN D 3-5
Edition 12.2003
Used for the
communications
partner
• SIMADYN D (only if PROFIBUS FDL is used as a
result of other communication partners)
• SIMATIC S5/S7
• Certified third-party equipment/devices
Hardware required
• Master: CS7 communications module with SS5
communications module
Communications
utility
• Process data
Central coupling
block
• @CSL2L
Features
• Standardized multi-master bus to couple SIMADYN D
(master) to a maximum of 126 coupling partners
• Token principle with secondary master-slave principle
• PROFIBUS Standard according to EN 50170
• Max. 1.5 Mbaud
• Maximum net data length 232 bytes
Table 3-6 PROFIBUS FDL coupling
Used for the
communications
partner
• SIMADYN D (only if PROFIBUS FMS is used as a
result of other communication partners)
• SIMATIC S5/S7
• Certified third-party equipment/devices
Hardware required
• Master: CS7 communications module with SS5
communications module
Communications
utility
• Process data
• Message system
Central coupling
block
• @CSL2F
Features
• Standardized multi-master bus to couple SIMADYN D
(master) to a maximum of 126 coupling partners
• Token principle with secondary master-slave principle
• PROFIBUS standard according to EN 50170
• Master-master- and master-slave communications
possible
• Max. 1.5 Mbaud
• Maximum net data length 232 bytes
• The bus can be parameterized using COM SS5
software
Table 3-7 PROFIBUS FMS coupling
PROFIBUS FDL
PROFIBUS FMS
