HMI menu ID Parameter Description Default value
[unit]
Value range Access
level
2.5.8.6.7 Partially Open Current
Level
Define current level to partly
close the analog valve.
10
[mA]
0 to 20 User
2.5.8.6.8 Fully Open Current Lev‐
el
Define current level to fully open
the analog valve.
20
[mA]
0 to 20 User
2.5.8.6.9 Fully Open Define the dosing amount value
at which the valve will transition
from partial flow to full flow.
0.0
[%]
0.0 to100.0 User
2.5.8.6.10 Partially Closed Define the dosing amount value
at which the valve will transition
from full flow to partial flow.
0.0
[%]
0.0 to100.0 User
2.5.8.6.9 Fully Open Define the dosing amount value
at which the valve will transition
from partial flow to full flow.
0.0
[kg]
User
2.5.8.6.10 Partially Closed Define the dosing amount value
at which the valve will transition
from full flow to partial flow.
1.0
[kg]
User
2.5.8.6.9 Fully Open Define the dosing amount value
at which the valve will transition
from partial flow to full flow.
0.0
L
User
2.5.8.6.10 Partially Closed Define the dosing amount value
at which the valve will transition
from full flow to partial flow.
1.00
L
User
2.5.8.6.9 Fully Open Define the dosing amount value
at which the valve will transition
from partial flow to full flow.
0.0
SL
User
2.5.8.6.10 Partially Closed Define the dosing amount value
at which the valve will transition
from full flow to partial flow.
1.00
SL
User
2.5.8.7 Fault Handling
2.5.8.7.1 Duration mode Enable or disable dosing time
supervision. An alarm is raised
and valve(s) closed if dosing
time is exceeded.
Off
● Off
● On
User
2.5.8.7.2 Duration time Define the supervision time. An
alarm is raised and valve(s)
closed if dosing time is excee‐
ded.
3600 1 to 360000 User
2.5.8.7.3 Overrun mode Enable or disable dosing
amount supervision. An alarm is
raised and valve(s) closed if dos‐
ing amount is exceeded.
Off
● Off
● On
User
2.5.8.7.4 Overrun value Define the dosing overrun
amount. An alarm is raised and
valve(s) closed if dosing amount
is exceeded.
0 User
