6 The settings in detail 07.05.2014
6.5.36 Operating level changeover via input H
Line no. Operating line
HC1 HC2 HC3
898 1198 1498 Operating level changeover
Frost protection
Reduced
Comfort
The operating level to which the heating circuits shall be switched can be selected via
an external time switch and inputs Hx.
6.5.37 Operating mode changeover via input H
The heating circuit can be forced to adopt a selectable operating mode via input H by
actuating a contact. The operating mode required when changeover takes place can be
defined for each heating circuit via the Optg mode changeover (900/1200/1500). In that
case, selection of the operating modes on the controller is disabled.
The contact type can be set.
Line no. Operating line
HC1 HC2 HC3
900 1200 1500 Optg mode changeover
None
Protection
Reduced
Comfort
Automatic
None
Function is deactivated.
Note!
A basic unit with LPB device address = 1 can provide the function of central operating
mode changeover. In that case, changeover on the central basic unit (via input H)
also acts on the heating circuits and on DHW heating of the other basic units
connected to LPB.
Line no. Operating line
6620 Action changeover functions
Operating level
changeover
Optg mode changeover
