Building Technologies Division User Manual LMS14... CC1U7471en
6 The settings in detail 07.05.2014
6.9.3 Overtemperature protection
Line no. Operating line
2070 Swimming pool temp max
If the swimming pool temperature reaches the limit set here, the collector pump is
deactivated. It is released again only when the swimming pool temperature drops 1 °C
below the maximum limit.
Figure 35: Overtemperature protection swimming pool temperature maximum
Key
Line no. Meaning
2070 TSbMax Maximum storage tank temperature (buffer/DHW/swimming pool)
8900 TSb Swimming pool temperature
6.9.4 Plant hydraulics
Line no. Operating line
2080 With solar integration
No
Yes
The setting made here decides whether the swimming pool can be heated by solar
energy.
