Building Technologies Division User Manual LMS14… CC1U7471en

6 The settings in detail 28.01.2015

6.15 Solar

6.15.1 General

The basic unit supports solar DHW heating or heating backup via a buffer storage tank.

Solar charging is performed with a single-speed charging pump on the basis of the

temperature differential between DHW storage tank and collector, or between buffer

storage tank and collector.

The LMS14… supports:

 One collector panel with sensor B6

 Collector pump Q5 (1-speed)

 One heat exchanger with sensor B3 or B31

 One heat exchanger with sensor B4 or B41

The following functions are available:

 dT control of DHW storage tank and buffer storage tank

 Minimum and maximum charging temperature

 Minimum running time

 Pump and valve kick

 Status display (operating state)

 Overtemperature protection for the collector

 Storage tank recooling via the collector

 Storage tank recooling via the boiler/space heating

 Frost protection for the collector

 Evaporation of collector medium (protection for the pump)

 Collector start

 Collector hours run

 Display of minimum and maximum collector temperature

Note!

A sensor B6 and collector pump Q5 must be parameterized at the multifunctional

inputs/outputs (BX, QX) for configuration of the solar diagram and for the associated

parameters to be displayed, or else the Solar DHW application must be used via an

extension module.
