35/617
Building Technologies Division User Manual LMS14... CC1U7471en
3 Mounting and installation 28.01.2015
3.6.1 Terminals of LMS14… complete (Deluxe)
LED flame
LED interference
Reset
Identification port
+12 V
CL+
GND
BSB bus room unit
Reset
Fan PWM
AGU2.56...
OCI430
Mains supply
7471a40e/1214
Ionization
Fuel valve
Ignition module
BSB bus room unit
Ionization
UX2
GND
UX3
GND
AUX1 /
fan
Figure 11: Terminals of LMS14… complete (Deluxe)
