6.29.2 Input test sensors
Line no. Operating line
7730 Outside temp B9
Line no. Operating line
7750 DHW temp B3/B38
Line no. Operating line
7760 Boiler temp B2
Line no. Operating line
7820 Sensor temp BX1
Line no. Operating line
7821 Sensor temp BX2
Line no. Operating line
7822 Sensor temp BX3
Line no. Operating line
7823 Sensor temp BX4
Line no. Operating line
7830 Sensor temp BX21 module 1
Line no. Operating line
7831 Sensor temp BX22 module 1
Line no. Operating line
7832 Sensor temp BX21 module 2
Line no. Operating line
7833 Sensor temp BX22 module 2
Line no. Operating line
7834 Sensor temp BX21 module 3
Line no. Operating line
7835 Sensor temp BX22 module 3
The input test is made to read the current measured values at the controller’s input
terminals. This facilitates straightforward checking of wiring.
