Building Technologies Division User Manual LMS14… CC1U7471en
6 The settings in detail 28.01.2015
6.24.4 Clock
Line no. Operating line
6640 Clock mode
Autonomously
Slave without remote setting
Slave with remote setting
Master
This setting defines the impact of the system time on the controller’s time setting.
The impact is as follows:
Autonomously
The time of day on the controller can be readjusted. The controller's time of day is not
matched to the system time.
Slave without remote setting
The time of day on the controller cannot be readjusted. The controller's time of day is
constantly and automatically matched to the system time.
Slave with remote setting
The time of day on the controller can be readjusted; at the same time, the system time
is readjusted since the change is adopted from the master. The controller's time of day
is still automatically and constantly matched to the system time.
Master
The time of day on the controller can be readjusted. The controller’s time of day is used
for the system. The system time is adjusted.
6.24.5 Outside temperature
Line no. Operating line
6650 Outside temp source
Only one outside sensor is required in LPB plant. This sensor is connected to a freely
selectable controller and delivers via LPB the signal to the controllers without sensor.
The first numeral to appear on the display is the segment number followed by the
device number.
– – . – – No outside sensor readable
01.02 Address of outside sensor
The first numeral corresponds to the segment number (01.)
The second numeral corresponds to the device number (.02)
Note!
If required (e.g. due to different exposure of certain buildings to solar radiation), the
different sections of the system can be equipped with their individual outside sensors.
