Siemens LMS14 User Manual

165/617
Building Technologies Division User Manual LMS14... CC1U7471en
6 The settings in detail 07.05.2014
6.5.31 Mixing valve control
Line no. Operating line
HC1 HC2 HC3
830 1130 1430 Mixing valve boost
To ensure proper flow temperature control via the mixing valve, the current flow
temperature must be higher than the flow temperature setpoint demanded for the
mixing valve. The value set here is added to the heat request.
Note!
If, in addition to mixing heating circuits, pump heating circuits are connected, the
pump heating circuits compensate the increased common flow temperature via the
Overtemperature protection function, and the heating circuit pump cycles accordingly.
Line no. Operating line
HC1 HC2 HC3
832 1132 1432 Actuator type
2-position
3-position
The selection of the type of actuator determines the control behavior of the mixing valve
actuator used.
The controller supports both 2-position and 3-position actuators.
2-position
The controller drives the actuator via one relay output. When the output delivers a
signal, the valve opens. If there is no signal, the valve closes automatically (thermally or
mechanically).
Note!
Control is accomplished with a 2-position controller having an adjustable switching
differential. If the flow temperature lies more than half the switching differential below
the setpoint, relay Mixing valve opening is energized and remains energized until the
flow temperature exceeds the setpoint by half the switching differential.
3-position
The controller drives the actuator via 2 relay outputs. One of the outputs is used for
opening the valve and one for closing it. If none of the relays is energized, the actuator
maintains its position.
Note!
Control is accomplished with a PID controller, whereby the mixing valve’s P-band
(Xp) and integral action time (Tn) can be adjusted. The actuator running time can
also be set. The controller’s neutral zone is ±1 K. In the case of difficult controlled
systems, the control parameters can be matched to the system.
Line no. Operating line
HC1 HC2 HC3
833 1133 1433 Switching differential 2-pos
With 2-position actuators, the 2-position switching differential must be adapted also.
This is not required with 3-position actuators.
Mixing valve boost
A
ctuator type
Switching differential
2-pos
