6 The settings in detail 28.01.2015
6.34.2 Ignition
Line no. Operating line
9512 Required speed ignition
Required speed at the time of ignition, which can be adjusted via the operator terminal.
It cannot be set to a value higher than Required speed ignition max (9513).
Line no. Operating line
9513 Required speed ignition max
Required speed ignition (safety-related). Limit value for the adjustable Required speed
ignition.
Line no. Operating line
9514 Speed tolerance ignition
Speed tolerance during the ignition phase. Required speed ignition plus/minus speed
tolerance ignition gives the permissible deviation of the speed during the ignition phase.
Line no. Operating line
9517 Preignition time
If the parameter is set to 0, phase TVZ lasts the minimum of 0.2 s.
Line no. Operating line
9518 Safety time
Total safety time. The safety time can be subdivided into a phase with and a phase
without ignition. Duration of safety time without ignition: Safety time minus safety time
with ignition.
Note!
The safety time (TSA) is set in increments of 200 ms. Due to the 1% tolerance of the
parameterized times and the switching times of the controlling elements, the next
lower value of the required maximum safety time must be parameterized.
If the maximum safety time shall be <5 seconds, the safety time to be set for the
LMS14... is 4.8 seconds.
Line no. Operating line
9519 Safety time with ignition
Safety time with ignition On.
Required speed
ignition
Required speed
ignition max
Speed tolerance
ignition
Preignition time
Safety time
Safety time with
ignition
