Building Technologies Division User Manual LMS14… CC1U7471en
6 The settings in detail 28.01.2015
6.34.3 Operation
Line no. Operating line
9524 Required speed LF
Speed required at low-fire, which can be adjusted via the operator terminal. It can only
be set to a value above the Required speed LF min (9525).
Line no. Operating line
9525 Required speed LF min
Speed required for low-fire minimum (safety-related). Limit value for Required speed LF
(9524).
Line no. Operating line
9526 Speed tolerance LF
Speed tolerance at low-fire. Required speed LF (9524) minus speed tolerance low-fire
gives the permissible deviation of the speed during the operating phase.
Line no. Operating line
9529 Required speed HF
Speed required at high-fire, which can be adjusted via the operator terminal. It cannot
be set to a value above the Required speed HF max (9530).
Line no. Operating line
9530 Required speed HF max
Speed required for high-fire maximum (safety-related). Limit value for Required speed
HF (9529).
Line no. Operating line
9531 Speed tolerance HF
Speed tolerance at high-fire. Required speed HF (9529) plus speed tolerance high-fire
gives the permissible deviation of the speed during the operating phase.
Line no. Operating line
9534 Optg time with ignition load
Control with ignition load prior to change to the operating phase (interval for
stabilization of flame).
Required speed
LF
Required speed
LF min
Speed tolerance
LF
Required speed
HF
Required speed
HF max
Speed tolerance HF
Optg time with
ignition load
