Siemens LMS14

28/617
Building Technologies Division User Manual LMS14... CC1U7471en
3 Mounting and installation 28.01.2015
3.4.2 Assignment of terminal X30
7471m22e/1214
LED flame LED interference
CL+ GND/CL-
Rv = external
Status LEDs
Uext 12 V
9 8 7 6 5 4 3 2 1
X30
Rv Rv
GND
ET
Figure 6: Assignment of terminal X30
