Building Technologies Division User Manual LMS14... CC1U7471en
3 Mounting and installation 28.01.2015
3.7 Cable AGU2.110x109
Dimensions in mm
Ribbon cable, 3-core, 2.5 mm grid, grey
E.g. FL 0.3 x 0.23, 1.35, 2.50 mm grid
Supplier: Klasing Kabel
Ribbon cable, 2-core, 2.5 mm grid, grey
E.g. FL 0.2 x 0.23, 1.35, 2.50 mm grid, Supplier: Klasing Kabel
5 connectors
Type 3515-1 05 K23
Supplier: Lumberg
Pin 1Pin 1Pin 1Pin 1Pin 1
Marking of outer conductor
7471m23e/0911
Figure 13: Cable AGU2.110x109
